GIGABYTE B760M E DDR5 Micro ATX Motherboard
  • GIGABYTE B760M E DDR5 Micro ATX Motherboard
  • GIGABYTE B760M E DDR5 Micro ATX Motherboard
  • GIGABYTE B760M E DDR5 Micro ATX Motherboard
App Order free home delivery

GIGABYTE B760M E DDR5 Micro ATX Motherboard

Price 14,800৳15,200৳
Regular Price 16,500৳
Status In Stock
Product Code 38546
Brand GIGABYTE

Key Features

  • Model: B760M E
  • Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
  • Supported RAM: 2x DDR5, Max 128GB 7200(OC)
  • Graphics Output: 1x HDMI, 1x DisplayPort, 1x D-Sub port
  • Features: Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
  • View More Info

Payment Options

Specification

Basic Information
Supported CPULGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors
L3 cache varies with CPU
ChipsetIntel B760 Express Chipset
BIOS1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form FactorMicro ATX Form Factor; 23.0cm x 21.5cm
AudioRealtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Expansion Slots
PCICPU:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
* The PCIEX16 slot can only support a graphics card or an NVMe SSD.

Chipset:
- 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Memory
TypeDDR5
Slots2
Supported MemorySupport for DDR5 7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory module
Maximum MemorySupporting up to 128 GB (64 GB single DIMM capacity) of system memory
Graphics
GraphicsOnboard Graphics
Integrated Graphics Processor-Intel® HD Graphics support:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3


- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version and HDCP 2.3.
** Support native HDMI 2.1 TMDS compatible ports.
Connector & Ports
HDMI1 x HDMI port
Display Port (s)1 x DisplayPort
D-Sub (s)1 x D-Sub port
USB (s)Chipset:
- 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s)Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Supported StorageCPU:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)(M2A_CPU)
Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support)(M2P_SB)
- 4 x SATA 6Gb/s connectors
RAIDRAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
Audio3 x audio jacks
Internal I/O PortsInternal I/O Connectors

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
2 x system fan headers
1 x RGB LED strip header
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x Clear CMOS jumper

Back Panel Connectors

2 x USB 2.0/1.1 ports
1 x D-Sub port
1 x DisplayPort
1 x HDMI port
4 x USB 3.2 Gen 1 ports
1 x RJ-45 port
3 x audio jacks
TPM (Trusted Platform Module )1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
Others
Special Features Support for GIGABYTE Control Center (GCC)
Support for Q-Flash
Bundled SoftwareNorton Internet Security (OEM version)
LAN bandwidth management software
Warranty Information
Manufacturing Warranty3 years Warranty

Description

GIGABYTE B760M E DDR5 Micro ATX Motherboard

The GIGABYTE B760M E DDR5 Micro ATX motherboard is crafted for users looking to push the limits of their system's performance and stay ahead in the ever-evolving world of computing. Supporting Intel’s 12th, 13th, and latest 14th-generation Core processors, this motherboard ensures maximum compatibility and enables smooth handling of demanding tasks, making it ideal for both gaming enthusiasts and professionals. At its core, the B760M E features a hybrid 6+1+1 phase digital VRM solution, providing a stable and efficient power delivery system that enhances CPU performance and ensures reliability under high workloads. This motherboard also excels in memory performance with its support for dual-channel DDR5. Equipped with two DIMM slots and XMP memory module support, it enables faster data transfers and more responsive applications. The leap to DDR5 memory, combined with the ease of upgrade options, makes it a future-proof choice for high-performance needs. The GIGABYTE B760M E is ready for next-generation speeds with two PCIe 4.0 x4 M.2 connectors. These slots facilitate ultra-fast data transfers, essential for gamers and content creators looking to reduce load times and boost productivity. Furthermore, the motherboard’s EZ-Latch design simplifies the installation of GPUs with its PCIe 4.0x16 slot, offering a quick-release mechanism that eliminates the need for tools. Connectivity is comprehensive, with DisplayPort, HDMI, and D-Sub options, allowing for flexible display configurations and multi-monitor setups. Coupled with GbE LAN, users benefit from fast and stable network connectivity, making it easy to stream, game, and transfer files without interruption. Efficient cooling is a priority with Smart Fan 6 technology, which includes multiple temperature sensors and hybrid fan headers. The fan stop feature further enhances the cooling efficiency and reduces noise by halting fans when the system is idle or under low load. This ensures quieter, energy-efficient operation while protecting the hardware during intensive tasks. The GIGABYTE B760M E DDR5 Micro ATX motherboard combines advanced features, future-ready compatibility, and a user-friendly design, making it an ideal choice for users seeking performance and convenience in their systems. Whether for gaming, productivity, or high-intensity computing, this motherboard provides a balanced, high-performance platform.

Buy GIGABYTE B760M E DDR5 Micro ATX Motherboard from the best Motherboard Shop in BD

In Bangladesh, you can get the original GIGABYTE B760M E DDR5 Micro ATX Motherboard From Star Tech. We have a large collection of the latest GIGABYTE Motherboard to purchase for your Desktop PC. Order Online Or Visit your Nearest Star Tech Shop to get yours at the lowest price. The GIGABYTE B760M E DDR5 Micro ATX Motherboard comes with 3 years warranty.

What is the price of GIGABYTE B760M E Motherboard in Bangladesh?

The latest price of GIGABYTE B760M E Motherboard in Bangladesh is 14,800৳. You can buy the GIGABYTE B760M E Motherboard at best price from our website or visit any of our showrooms.
