GIGABYTE H610M K DDR5 Micro ATX Motherboard
  • GIGABYTE H610M K DDR5 Micro ATX Motherboard
  • GIGABYTE H610M K DDR5 Micro ATX Motherboard
Product After image | Nagad cashback

GIGABYTE H610M K DDR5 Micro ATX Motherboard

Price 11,200৳11,500৳
Regular Price 12,430৳
Status In Stock
Product Code 37017
Brand GIGABYTE

Key Features

  • Model: H610M K DDR5
  • Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
  • Supported RAM: 2x DDR5, Max 128GB 5333(OC)
  • Graphics Output: 1x HDMI 2.1, 1 x DisplayPort
  • Features: Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
  • View More Info

Payment Options

Specification

Basic Information
Supported CPULGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core, Pentium Gold and Celeron Processors
L3 cache varies with CPU
(Please refer "CPU Support List" for more information.)
ChipsetIntel H610 Express Chipset
BIOS1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form FactorMicro ATX Form Factor; 23.0cm x 21.5cm
AudioRealtek Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Support for S/PDIF Out
Expansion Slots
PCICPU:
- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
Chipset:
- 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Memory
TypeDDR5
Slots2 x DIMM sockets
Supported MemorySupport for 5600/5200/4800/4400 MT/s memory modules
13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors:
4800/4400 MT/s memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memor
Maximum MemorySupporting up to 128 GB (64 GB single DIMM capacity) of system memory
Graphics
GraphicsIntegrated Graphics Processor-Intel HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version and HDCP 2.3.
** Support native HDMI 2.1 TMDS compatible ports.


- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3


(Graphics specifications may vary depending on CPU support.)
Connector & Ports
HDMI1 x HDMI port
Display Port (s)1 x DisplayPort
USB (s)Chipset:
- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
LAN Port (s)Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Supported StorageChipset:
- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 3.0 x4/x2 SSD support)
- 2 x SATA 6Gb/s connectors
Internal I/O PortsInternal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x M.2 Socket 3 connector
2 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Clear CMOS jumper

Back Panel Connectors
1 x HDMI port
1 x DisplayPort
2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
TPM (Trusted Platform Module )1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
Others
Special Features iTE I/O Controller Chip
Bundled SoftwareNorton Internet Security (OEM version)
LAN bandwidth management software
Warranty Information
Manufacturing Warranty3 years Warranty

Description

GIGABYTE H610M K DDR5 Micro ATX Motherboard

The GIGABYTE H610M K DDR5 Micro ATX motherboard is a compact and versatile platform designed to support the latest Intel processors, including the 14th, 13th, and 12th Gen CPUs with an LGA1700 socket. It provides robust performance and future-proofing for various computing needs, from gaming to content creation. This motherboard supports up to 4x DDR5 DIMMs, allowing for a maximum memory capacity of 64GB at speeds up to 3200 MHz, utilizing Dual Channel Non-ECC Unbuffered memory architecture. The GIGABYTE H610M K DDR5 features a single HDMI 2.1 port for high-definition graphics output and is equipped with a Realtek GbE LAN chip that supports up to 1 Gbps network speeds, with additional support for 100 Mbps connections and bandwidth management capabilities. It offers fast storage options through an NVMe PCIe 3.0 x4 M.2 slot, reducing load times for applications and games. High-quality audio capacitors and an audio noise guard ensure clear and immersive sound quality, enhancing the overall user experience. For efficient cooling and noise management, the Smart Fan 6 feature includes multiple temperature sensors and hybrid fan headers with a fan stop function. The motherboard also comes with the GIGABYTE APP Center, a user-friendly interface for managing system settings and features. Designed for durability, the GIGABYTE H610M K DDR5 incorporates an Anti-Sulfur resistor design, enhancing the longevity and reliability of the components. This motherboard is an excellent choice for building a high-performance PC with the latest technology and features.

Buy GIGABYTE H610M K DDR5 Micro ATX Motherboard from the best Motherboard Shop in BD

In Bangladesh, you can get the original GIGABYTE H610M K DDR5 Micro ATX Motherboard From Star Tech. We have a large collection of the latest GIGABYTE Motherboard to purchase for your Desktop PC. Order Online Or Visit your Nearest Star Tech Shop to get yours at the lowest price. The GIGABYTE H610M K DDR5 Motherboard comes with a 3-year warranty.

What is the price of GIGABYTE H610M K DDR5 Motherboard in Bangladesh?

The latest price of GIGABYTE H610M K DDR5 Motherboard in Bangladesh is 11,200৳. You can buy the GIGABYTE H610M K DDR5 Motherboard at best price from our website or visit any of our showrooms.
